EarthQuaker Devices Gary Fuzz Pedal

The EarthQuaker Devices Gary is a 2-in-1 pedal with a fuzz on the right side & OpAmp overdrive on the left. Featuring an automatic pulse width envelope filter that effects the fuzz channel.

OR

h m s

free-shipping-icon
In Stock!
Remove one item Add one item

Compare

Compare! Here are all the serial numbers of this model we have in stock. Compare them all and select your favorite!

    2 Day Shipping Icon

    Fast & Free Shipping

    Did you know AMS is the only music distributor with four distribution centers? And that means we can offer super-fast shipping on all your music products. Whether you don’t want the spark of inspiration to fade or you really need that replacement speaker before the next show, we have you covered anywhere in the U.S. And even better, it’s FREE!

    Free Extended Warranty

    Free 12 Month Extended Warranty

    You shouldn’t have to pay extra for a little peace of mind. When you purchase from AMS, you’ll get a free 12-month extended warranty to cover your purchase — and that’s in addition to any manufacturer’s warranties! Thousands of items in our catalog feature the “Gold Lock Extended Warranty,” so you can feel confident in your purchase.

    45 Day return

    Sometimes the gear on the computer screen seems like a better fit than when you actually get your hands on it. We understand, and that’s why AMS offers an industry-leading 45-day money-back guarantee. If you’re not happy with an item, you have a full month and a half to send it back! We don’t want to just sell you gear. We want to sell you the RIGHT gear — even if it takes a few tries.

    Canadian Shipping Information

    Welcome Canadian musicians! Buying your gear from AMS is as easy as going to a local music store, with more selection and more than competitive prices!

    Items with this logo are eligible to ship to Canada. Please note that you will be responsible for payment of brokerage fees, duties and other import taxes applicable to your order.

    NOTE: Free shipping offers do not apply to Canadian orders. Please be aware of custom fees - such as taxes and duties - when your order arrives. Since these fees vary from location to location, CUSTOMS FEES ARE NOT INCLUDED IN SHIPPING CHARGES. Please check with your local customs office for more information on the fees in your areas. Refusal to pay these fees will result in an undeliverable order. If returned, we do not refund shipping charges and may assess restocking fees to cover return shipping expenses.

    Rock Now Pay Later

    0% Interest Payment Plan

    Don’t sell your soul to a creditor to get the gear you need. At AMS, we want to lower the barriers to create. That’s why we offer in-house 0% financing, and you don’t even have to open a new line of credit! Spread out payments on your credit card to simplify financing and avoid hefty late fees or service charges. Cost shouldn’t interfere with your creativity.

    Non Factory Sealed Items

    Non Factory Sealed are items that have been opened but are in perfect physical condition such as customer returns, open box for product photos/videos, demo stock, etc. They have been carefully inspected and repacked by qualified AMS employees to help ensure your satisfaction, allowing you to get great gear at a discounted price. They include all components, manuals and the full Manufacturer's warranty unless otherwise stated, along with the AMS 45-day Money-Back Guarantee. Special offers, promotions and rebates may not apply. The following manufacturers do not offer a warranty on Non-Factory Sealed items: Casio, Ampeg, Avalon, Chauvet, Electro-Voice, Ibanez, Mackie, Martin, Peavey

    AMS Agent

    Have questions?
    Talk to a sales specialist!

    800-319-9043

    Gary - Automatic Pulse Width Modulation Fuzz and Dynamic Natural Overdrive

    EarthQuaker Devices is proud to introduce you to your new best bud, Gary. This little big guy was dreamt up by the one and only Lee Kiernan from the crushing and most necessary band, Idles!



    EarthQuaker Devices Gary Fuzz Pedal Features:

    • A compact version of the now discontinued Gray Channel
    • Right side consists of a dynamic yet destructive fuzz
    • Fuzz turns the signal into a square wave for a dynamic touch
    • Left side is a simple and natural sounding overdrive
    • Overdrive is based on the classic little yellow overdrive
    • Unique and one-of-a-kind controls for a unique and one-of-a-kind pedal
    • Tones can range from a simple clean boost to a smooth and natural distortion
    • Yes!: controls the sensitivity of the envelope
    • Oosh: is the master volume for the fuzz side
    • Go sets the gain of the opamp drive
    • That’s It: Master volume for the overdrive side
    • Expression Pedal jack that controls the pulse width of the envelope filter
    • Fixed signal path of fuzz into overdrive for total tonal integrity
    • Flexi-Switch Technology for simultaneous use of momentary & latching style switching
    • Requires a standard 9-volt DC power supply



    Gary started as a simple request to create a compact version of the now discontinued Gray Channel, which was a mainstay on Lee’s board and a big part of his main drive tone. This was all fine and good, and sounded quite sick, but Gary was demanding that we look deeper and explore his dark side a little more, Gary after dark, Saturday night Gary. So, we sat him down and began the trek of figuring old Gare-Bear out once and for all. The result is a real exercise in light and dark; smooth to shredded and everything in between.



    Gary’s right brain consists of a dynamic and destructive fuzz that is both domineering and interactive. It is a ripping fuzz tone with an envelope-controlled variable pulse width and enough volume to blow everything up. This nasty little fuzz turns the signal into a square wave and allows you to dynamically adjust the duty cycle with pick attack.



    Yes! Controls the sensitivity of the envelope. When this is all the way down you will get an unadulterated thick and heavy square wave fuzz tone that will sustain for days and go dead quiet when you stop playing. As you increase the Yes! control, the envelope becomes more interactive, and the pulse width narrows the harder you hit it. As the pulse width narrows, the tone becomes more nasal and biting until it gets so narrow that Gary goes to his dark place and disappears completely. In other words, with higher sensitivity settings, the sound will disappear entirely and come cruising back to Gary’s big guy tone. With proper playing dynamics, this creates a very cool effect that can sound like an exploding amp coming in and out of life, blown through a phase shifter.



    This effect can also be controlled with an expression pedal for manual operation or for finding just the right pulse width to cut through the mix for a set-and-forget operation. When using an expression pedal, Yes! operates in conjunction with the expression pedal to set the peak of the sweep. Set Yes! to the desired stopping point and express yourself as you please with out worry of taking Gary over the edge!



    Oosh acts as the master volume for Gary’s nasty side. There is an insane amount of volume on tap so use this control wisely!



    Gary’s left brain displays his softer side. This is a simple and natural sounding overdrive that keeps your tone lively and drives your amp crazy. This side is based on the green channel of our Gray Channel, which is our take on the classic little yellow overdrive that started it all for us. Lee used this pedal with the clipping switch permanently set to the middle position, which removes all the diodes from the circuit, producing a full-bodied, cutting opamp distortion with plenty of volume on tap. We have reproduced that tone here with exacting precision.



    Go sets the opamp drive and can range from a simple full-range clean boost all the way up to a smooth and natural distortion. In conjunction with That’s It, which is the master volume for the drive side, you can use Gary’s softer side as a clean boost to push your amp into overdrive or turn up Go and use all of Gary’s internal magic to create the finely tuned dirt you desire.



    Gary’s signal path is fuzz into overdrive for total tonal integrity and cannot be changed. This is where Gary put his foot down, and we obliged. Each and every Gary was softly brought to life by the delicate hands of EarthQuaker Devices in the elegantly unrefined canal-front city of Akron, Ohio USA.



    Controls

    • Yes!: Sets the sensitivity for the envelope that controls the duty cycle for the square wave fuzz.
      • The envelope is highly dependent on the level of the incoming signal, which can be affected by any gain pedals in front of Gary, pickup strength, source instrument, etc.
      • For best results, place Gary near the front of the signal chain to get the most dynamic response from the envelope.Once this control gets around noon, the pulse becomes so narrow that the signal will disappear. This is completely normal.
    • Oosh: Master volume for the fuzz side.
    • Go: Gain control for the overdrive. Turn this up to increase the opamp gain to a thick and full distortion or turn it down and turn up
    • That’s It to use it as a clean boost.That’s It: Master volume for the overdrive side.
    • EXP: Controls the pulse width with an expression pedal. This will defeat the internal envelope and allow you to adjust the duty cycle in real time. Note that the Yes! Control remains active when an expression pedal is in use and sets the peak of the sweep, allowing you to fine tune the range.
      • PRO TIP: Plug a dummy cable into the expression jack to defeat the envelope and use the Yes! Control to hard-set the duty cycle to find your perfect ripping fuzz tone!
    • Right Footswitch: Fuzz
    • Left Footswitch: Overdrive



    Flexi-Switch Technology

    This device features Flexi-Switch Technology! This relay-based, true bypass switching style allows you to simultaneously use momentary and latching style switching.

    • For standard latching operation, tap the footswitch once to activate the effect and then
    • tap again to bypass.
    • For momentary operation, hold the footswitch down for as long as you’d like to use the effect. Once you release the switch, the effect will be bypassed.
    • Since the switching is relay based, it requires power to pass signal.



    Power

    This device requires a standard 9 volt DC power supply with a 2.1mm negative center barrel. We always recommend pedal-specific, transformer-isolated wall-wart power supplies or multiple isolated-output supplies. Pedals will make extra noise if there is ripple or unclean power. Switching-type power supplies, daisy chains and non-pedal specific power supplies do not filter dirty power as well and let through unwanted noise.



    DO NOT RUN AT HIGHER VOLTAGES!

    CALIFORNIA PROPOSITION 65 WARNING

    WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

    Shop Similar Models

    EarthQuaker Devices Gary Fuzz Pedal Specifications

    EarthQuaker Devices Gary Fuzz Pedal Specifications
    Product Specifications

    EarthQuaker Devices Gary Fuzz Pedal Specifications:

    • Current Draw: 20 mA
    • Fuzz Channel:
      • Input Impedance: 1M
      • Output Impedance: < 1K
    • Overdrive Channel:
      • Input Impedance: 500K
      • Output Impedance: < 1K
    • Artwork By: Charlotte Gosch
