Neutrik NC3FP1 XLRF Connector with Silver Contacts Specifications
| Product Specifications | Specifications: Connection Type: XLR Gender: female Electrical Capacitance between contacts: = 4 pF Contact resistance: = 5 m OHMS (inner) Dielectric strength: 1,5 kVdc Insulation resistance: > 2 G OHMS (initial) Rated current per contact: 16 A Rated voltage: 50 V MechanicalInsertion force: = 20 N Withdrawal force: = 20 N Lifetime: > 1000 mating cycles Wiring: Solder contacts Locking device: Latch lock Mounting direction: front Chassis shape: P MaterialContact plating: 2 µm Ag over 2 µm Ni Contacts: Bronze (CuSn6) Insert: Polyamide (PA 6.6 30 % GR) Locking element: Stahl Ck67Shell: Zinc diecast (ZnAl4Cu1) Shell plating: NickelEnvironmental Flammability: UL 94 HB Standard compliance: IEC 61076-2-103 Protection class: IP 40 Solderability: Complies with IEC 68-2-20 Temperature range: -30 degreesC to +80 degreesC |
|---|
