    The PZ-DI is a high-performance specialized active direct box designed to accommodate acoustic and orchestral instruments, with a selectable input impedance that can accommodate magnetic pickups or piezo transducers, and a variable low-cut filter. Unlike most direct boxes that are limited to a 'one size fits all' design, the PZ-DI lets you properly match the input impedance to the source to optimize the frequency response, dynamics and feel so that no matter what type of pickup you employ, you will enjoy smoother, more musically pleasing results.

    Radial PZDI Active Direct Box for Acoustic Instruments Features
    • Optimized for orchestral instruments on a live stage
    • Adjustable load for piezo and magnetic pickups
    • Variable low-cut filter to control low frequency resonance
    • Powered by 48V phantom, no batteries required
    Piezo problem solver
    The PZ-DI has a variable load selector switch that allows you to set the input impedance of the direct box, so you can optimize the performance with your instrument's pickups. The 1 meg ohm position delivers the classic impedance found on most active DI boxes, while the 220k ohm setting warms up the tone of magnetic pickups to provide the feel and tone as if your instrument were connected directly to an amplifier. The third setting is an ultra-high 10 meg ohm impedance that is specifically designed for piezo transducers, helping compensate for the harsh or squawky tone that can occur when a piezo is connected to a lower impedance input.

    Variable filter to suit any instrument
    To remove unwanted resonance on stage and prevent feedback, the PZ-DI is equipped with a fully-variable low-cut filter that gently rolls off low frequencies. The roll-off point of this filter can be raised or lowered to match the frequency response of your instrument, with a lower point for acoustic bass and a higher setting for violin or banjo. A switchable high-cut filter is also included, which is useful on instruments such as acoustic guitars that incorporate a battery-powered preamp, softening any harshness or high frequency edge for a smoother tone.

    Using the PZ-DI with a piezo
    Piezo pickups often sound harsh and unnatural. The PZ-DI solves the problem with a 10 meg-ohm input impedance that extends the frequency response and smoothes out the peaky edges. Adjust the low-cut filter to size the instrument and reduce unwanted resonance.

    Using the PZ-DI with active acoustics
    The convenience of a built-in pickup and battery powered preamp makes it easy to plug-in and play. But with less than ideal electronics, these instruments end to sound brittle and unnatural. The PZ-DI helps with a low-pass filter that gently smoothes the top end plus a variable low-cut filter to eliminate resonance.

    Using the PZ-DI with a magnetic pickup
    Optimize the tone of the bass by setting the load to 220k-ohm. This produces a warmer tone and natural feel that is particularly useful when recording or when preparing to Reamp. When touring with low-output vintage instruments, set the impedance to 1 meg-ohm to reduce the load.

    CALIFORNIA PROPOSITION 65 WARNING

    WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

    Shop Similar Models

    Radial PZDI Active Direct Box for Acoustic Instruments Specifications

    Radial PZDI Active Direct Box for Acoustic Instruments Specifications
    Product SpecificationsRadial PZDI Active Direct Box for Acoustic Instruments Specifications
    • Audio circuit type: Proprietary analog circuit with low-noise FET op-amp
    • Frequency response: 20Hz ~ 20kHz
    • Dynamic range: 105dB
    • Equivalent input noise: -98dBu
    • Maximum gain: +4.6dB
    • Total harmonic distortion: 0.02% /td>
    • Input impedance: 10M/1M/220K-Ohms
    • Input impedance with PAD on: 50K-Ohms
    • Output impedance: 200 Ohms - nominal
    • Input pad: -15dB
    • XLR configuration: AES standard (pin-2 hot)
    • Power: 48V phantom - proprietary digital switching
    • Construction: 14 gauge steel chassis and outer shell
    • Finish: Durable powder coat
    • Size: (W x H x D) 3.3 x 5 x 2” (84 x 127 x 48mm)
    • Weight: 1.2 lb (544 g)
