    With effortless, wide-open sonic performance and the ability to drive any pair of headphones without compromise, the RNHP allows you to perform, mix and enjoy your music with a new level of clarity. Whether you’re tracking, mixing, or just listening to music, your headphone amplifier is as important to the final sound quality as your headphones so Rupert and his team at Rupert Neve Designs have developed the RNHP.

    Rupert Neve Designs RNHP Precision Headphone Amp Features
      Precision Sound
      Wide-open, extremely detailed sound quality allows you to get the most out of your headphones

      Dedicated Power
      High-power, high-headroom design can effortlessly drive high-impedance (up to 600 Ohm) headphones even during the loudest, most dynamic tracking sessions

      Reliable Translation
      The near-zero output impedance (.01 Ohm at 1kHz), direct-coupled amplifier design provides for excellent translation with any pair of headphones

      Precision Stereo Potentiometer
      The highly damped stereo potentiometer is designed to give you precise level control and maintain perfect left-right balance

      Professional Line Input
      The calibrated +4dBu line input is selected with the “A” switch. The combo jack accepts either XLR or TRS inputs for balanced professional devices.

      RCA Input
      The unbalanced RCA input is calibrated for -10dBV signals and is selected with the “B” switch. The RCA jack is commonly used with home stereo devices or Prosumer equipment

      3.5mm Input
      Stereo 3.5mm input specifically calibrated to work with mobile devices like phones, computers and digital cameras

      VESA Mount
      The VESA 100 compatible mount enables you to mount the RNHP wherever it needs to be. Common mounts are pole-mount arm for mic stands, pivoting multi-arm desk mount, and wall / surface mount for securing upside-down under a table, music stand or other studio furniture

      Steel Clamshell Chassis
      The RNHP’s rugged, solid-steel chassis is built to a high industrial standard with an overhang to protect the connectors and main level control from glancing blows, as well as shock-absorbing rubberized feet

      24V DC Input
      The RNHP can be powered using either the included 6 watt power supply or a 24V, 0.25A min battery (not sold by RND)
    Based on the headphone output circuit in the 5060 Centerpiece Desktop Mixer, the RNHP is a dedicated 24V reference-quality headphone amplifier with specifically-calibrated +4dBu balanced line, unbalanced RCA and 3.5mm (1/8”) inputs, housed in a rugged VESA-mountable steel chassis.

    Dedicated vs Integrated Amplifiers
    For much equipment, the headphone output is an afterthought. Most products with integrated headphone amps have large feature sets, small footprints, and relatively low price points. This leads to comprised power and audio quality of the headphone amplifier itself, which can lead to a number of issues in real world usage such as low headroom, unreliable performance, and a lack of focus.

    The RNHP was made to accomplish one simple purpose: making any headphones sound their best. As a dedicated design, the RNHP is tailored to deliver extremely high quality, powerful amplification, with precise calibration for any source input. This exceptional level of quality can be the difference that inspires an artist to give their best performance, lets an engineer make better choices in mic and placement, gives a mix engineer reliable translation of EQ and dynamics adjustments, or lets a music listener appreciate the full depth and detail of a recording.

    Specially-Calibrated Inputs For All of Your Devices
    In addition to being able to drive a wide variety of headphones without sacrificing performance, the RNHP is also capable of receiving a wide array of signals with its 3 inputs, calibrated for optimum level and impedance. Check the Application notes for how the RNHP can be utilized for different purposes.

    Here are some common device examples:
      Input A: +4dBu Line (XLR or TRS) Devices
      Studio Audio Interfaces (Line or Monitor Out)
      Headphone Mixers (Line Output or HP Out)
      Mixing Consoles (Line, Aux or Monitor Out)
      Professional Turntable Mixers (Line or Monitor)
      Professional Stereo Digital to Analogue Converter
      Professional Camera
      Studio Monitor Controllers

      Input B: RCA Devices
      CD / DVD Players
      Stereo Tuners
      Preamplified Turntables
      Prosumer Recording Devices / Cameras

      Input C: 3.5mm (1/8") Stereo Devices
      Mobile Phones
      Portable Music Players
      Computers
      DSLR Cameras
      Handheld Recording Devices
      Any 3.5mm headphone output
    VESA-Mountable Design
    The RNHP is designed for mounting with any VESA 100 compatible mount. These may include pole mounts, wall mounts, table mounts, or articulating arm mounts. These mounts can help to ensure the RNHP is always in the perfect position.

    Multiple-Line Feed
    In some situations where you only have one set of outputs but need to simultaneously feed the RNHP and another device such as speakers, a second headphone amplifier, or a 2-track recorder, we recommend using splitter cables from the Left and Right line outputs to feed both devices from the same stereo pair.

    CALIFORNIA PROPOSITION 65 WARNING

    WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

    Shop Similar Models

    Rupert Neve Designs RNHP Precision Headphone Amp Specifications

    Rupert Neve Designs RNHP Precision Headphone Amp Specifications
    Product SpecificationsRupert Neve Designs RNHP Precision Headphone Amp Specifications
      Maximum Input Levels

      "A" XLR I/P: +22.8 dBu @1kHz
      "B" RCA I/P: +14.7dBu @1kHz,
      "C" 3.5mm I/P: +3.3dBu @1kHz

      Output Power:

      As measured with typical headphones, Z=44 Ω: 3.617 VAC RMS @1kHz = 300mW RMS
      16 Ω typical Load: 1.933 VAC RMS @1kHz = 230mW RMS
      150 Ω typical Load: 5.108 VAC RMS @1kHz = 175mW RMS

      Output Impedance

      .08 Ω @ 1KHz, 16-150 Ω load, 0dBu input

      Frequency Response

      +/- .2dB from 10Hz to 120KHz

      Noise

      Measured with typical headphones, Z=44 Ω, BW 22Hz – 22kHz
      "A" XLR Input: -101.9dBV,
      "B" RCA Input: -100.9dBV
      "C" 3.5mm Input: -88.8dBV

      Dimensions

      6.5” wide x 4.6” deep and 1.9” tall

      Power Supply Requirements

      24VDC @ 0.25Amp (6 watt) minimum. Use with supplied power adapter, as this has been carefully selected for best output power and noise performance. May be used with a properly configured 24V battery as well.
