TASCAM Model Series Studio Bridge 24 Track Recorder

The Tascam Studio Bridge is literally the bridge between analog mixers & digital recording devices. Mix & record 24 tracks of lush analog tone to a DAW or the on-board multitrack recorder.

OR
In Stock!
Remove one item Add one item

Compare

Compare! Here are all the serial numbers of this model we have in stock. Compare them all and select your favorite!

    2 Day Shipping Icon

    Fast & Free Shipping

    Did you know AMS is the only music distributor with four distribution centers? And that means we can offer super-fast shipping on all your music products. Whether you don’t want the spark of inspiration to fade or you really need that replacement speaker before the next show, we have you covered anywhere in the U.S. And even better, it’s FREE!

    Free Extended Warranty

    Free 12 Month Extended Warranty

    You shouldn’t have to pay extra for a little peace of mind. When you purchase from AMS, you’ll get a free 12-month extended warranty to cover your purchase — and that’s in addition to any manufacturer’s warranties! Thousands of items in our catalog feature the “Gold Lock Extended Warranty,” so you can feel confident in your purchase.

    45 Day return

    Sometimes the gear on the computer screen seems like a better fit than when you actually get your hands on it. We understand, and that’s why AMS offers an industry-leading 45-day money-back guarantee. If you’re not happy with an item, you have a full month and a half to send it back! We don’t want to just sell you gear. We want to sell you the RIGHT gear — even if it takes a few tries.

    Canadian Shipping Information

    Welcome Canadian musicians! Buying your gear from AMS is as easy as going to a local music store, with more selection and more than competitive prices!

    Items with this logo are eligible to ship to Canada. Please note that you will be responsible for payment of brokerage fees, duties and other import taxes applicable to your order.

    NOTE: Free shipping offers do not apply to Canadian orders. Please be aware of custom fees - such as taxes and duties - when your order arrives. Since these fees vary from location to location, CUSTOMS FEES ARE NOT INCLUDED IN SHIPPING CHARGES. Please check with your local customs office for more information on the fees in your areas. Refusal to pay these fees will result in an undeliverable order. If returned, we do not refund shipping charges and may assess restocking fees to cover return shipping expenses.

    Rock Now Pay Later

    0% Interest Payment Plan

    Don’t sell your soul to a creditor to get the gear you need. At AMS, we want to lower the barriers to create. That’s why we offer in-house 0% financing, and you don’t even have to open a new line of credit! Spread out payments on your credit card to simplify financing and avoid hefty late fees or service charges. Cost shouldn’t interfere with your creativity.

    AMS Agent

    Have questions?
    Talk to a sales specialist!

    800-319-9043

    The Model Series Studio Bridge is quite literally the bridge between analog mixers and digital recording devices whether you use a DAW or prefer a DAWless setup. Preserve the lush analog tone from your mixing console while tracking and mixing to your DAW of choice or to the Studio Bridge's on-board multitrack recorder. Tracks recorded to the on-board recorder or your DAW can be returned to your analog console for mix summing, turning digital recordings into warm analog productions. Whether tracking at a personal recording studio or a live environment, the Studio Bridge handles all your needs with ease. The Model Series Studio Bridge is quite literally the bridge between analog mixers and digital recording devices whether you use a DAW or prefer a DAWless setup. Preserve the lush analog tone from your mixing console while tracking and mixing to your DAW of choice or to the Studio Bridge's on-board multitrack recorder. Tracks recorded to the on-board recorder or your DAW can be returned to your analog console for mix summing, turning digital recordings into warm analog productions. Whether tracking at a personal recording studio or a live environment, the Studio Bridge handles all your needs with ease.



    TASCAM Model Series Studio Bridge 24 Track Recorder Features

    • 24-track multitrack recorder using SDXC SD card (punch-in/out supported)
    • 24-IN/24-OUT USB audio interface
    • 24 DB25 analog line level input and output
    • DAW transport control and REC READY control via HUI/MCU
    • Dedicated Settings Panel application with Meter Bridge
    • MIDI in/out allows USB MIDI interface and MIDI sync, 1/4" audio click output with tempo control



    What's in the box

    • Studio Bridge × 1
    • Power cord × 1
    • Safety guide (including warranty) × 1
    • TASCAM ID registration guide × 1
    Shop Similar Models

    TASCAM Model Series Studio Bridge 24 Track Recorder Specifications

    TASCAM Model Series Studio Bridge 24 Track Recorder Specifications
    Product Specifications

    TASCAM Model Series Studio Bridge 24 Track Recorder Specifications

    • Recorder Specs
      • Supported media: SD (512 MB to 2 GB), SDHC (4 GB to 32 GB), SDXC (64 GB to 512 GB)
      • Recording format: WAV (BWF)
      • Playback format: WAV (BWF)
      • Sampling rate: 44.1/48 kHz
      • Quantization bit depth: 16-bit / 24-bit
      • Maximum number of recording tracks: 24
      • Maximum number of input and output channels: Inputs: 24 / Outputs: 24
    • Analog audio input/output ratings
    • Line input connectors (1–8, 9–16, 17–24):
      • Connector: 25-pin balanced D-sub
      • Fixed screws: No. 4-40 UNC (inch type)
      • Maximum input level: +24 dBu
      • Nominal input level: +4 dBu
      • Input impedance: 10 kΩ or more
        • Pin assignments same for 1–8, 9–16 and 17–24
        • TASCAM DB-25 Pinout Standard (AES59-2012 compliant)
    •  Line output connectors (1–8, 9–16, 17–24):
      • Connector: 25-pin balanced D-sub
      • Fixed screws: No. 4-40 UNC (inch type)
      • Maximum output level: +24 dBu
      • Nominal output level: +4 dBu
      •  Output impedance: 200 Ω
        • Pin assignments same for 1–8, 9–16 and 17–24
        • TASCAM DB-25 Pinout Standard (AES59-2012 compliant)
    •  Headphones/Local Monitor Jack:
      • Connector: 6.3mm (1/4") standard stereo jack
      • Maximum output: 80 mW + 80 mW (into 32Ω load)
      • Working impedance: 16 to 600 Ω
    • Control input/output ratings
      • USB:
        • Connector: USB Type-B
        • Transfer format: USB 2.0 High-Speed
        • Device classes: Mass storage, USB audio class 2.0 (USB class compliant)
    • USB audio:
      • Sampling rate: 44.1 kHz / 48 kHz
      •  Quantization bit depth: 24-bit
      • Number of inputs: 24 channels (Output from this unit)
      • Number of outputs: 24 channels (Input to this unit)
    • CLICK OUT jack:
      • Connector: 6.3mm (1/4") standard TRS jack (Tip: HOT, Ring: COLD, Sleeve: GND)
    •  FOOTSWITCH jack:
      • Connector: 6.3mm (1/4”) standard TRS jack (Tip: FOOTSW1, Ring: FOOTSW2, Sleeve: GND, supports momentary (unlatch) types)
    •  MIDI OUT connector
      • Connector: 5-pin DIN
      • Format: MIDI 1.0
    • MIDI IN connector
      •  Connector: 5-pin DIN
      •  Format: MIDI 1.0
    • Utility Specs Power: AC 100-240 V, 50/60 Hz
    • Power consumption: 20W
    • Dimensions (WxHxD, including protrusions):
      • With side panels: 446.5 × 114.6 × 269.5 mm
      • Without side panels: 414.6 × 114.6 × 269.5 mm
    • Weight: 4.5kg
    • Operating temperature range: 0–40°C (32–104°F)
    • Operating humidity range: 5–85% (without condensation)
    • Audio performance (Line in ➝ line out for both 44.1kHz and 48kHz sampling rates)
    • Frequency response: 20 Hz – 20 kHz (+0.3/−0.7 dB, 1 kHz)
    • Dynamic range: 100 dB or more (22kHz LPF + A-weight)
    • Total harmonic distortion ratio (THD+N):0.003% or less (1 kHz, at maximum input level)
    • Crosstalk: −100 dB or less (1kHz BPF)
    • Recording Times, with 32GB card (for WAV files w/24 tracks):
      • 16-bit/44.1kHz: 4hrs 10min
      • 16-bit/48kHz: 3hrs 50min
      • 24-bit/44.1kHz: 2hrs 47min
      • 24-bit/48kHz: 2hrs 33min
